Automatic Cobot Palletizer Robot Arm for Carton Box

Hot Product

Automatic Cobot Palletizer Robot Arm for Carton Box

This Cobot Palletizer delivers automated case stacking with 20kg, 30kg, and 50kg payload options, working safely alongside operators in compact spaces.

Automatic Cobot Palletizer

Introduction:

Manual carton palletizing causes strain injuries, high labor costs, and end-of-line bottlenecks. Traditional industrial robots require bulky safety cages and large footprints. This collaborative robot palletizer delivers automated case stacking with 20kg, 30kg, and 50kg payload options, working safely alongside operators in compact spaces.

Features:

1. 20kg, 30kg, and 50kg Payload Configurations:

Available in 20kg, 30kg, and 50kg payload capacities, this cobot palletizer handles retail boxes, food cartons, and heavy industrial packs. High-torque joints and rigid arm construction ensure precise, stable placement at full reach and maximum payload.

2. Fenceless Collaborative Safety and Small Footprint:

Equipped with collision detection and speed monitoring, the cobot operates safely next to workers without safety fences. Its compact base fits tight spaces where traditional robot cells cannot fit, preserving valuable floor space.

3. Dual Pallet Stations for Non-Stop Palletizing:

The system supports dual-pallet layouts. While the arm stacks cartons on one pallet, operators remove the finished pallet from the adjacent station without stopping line flow, maintaining continuous output.

4. Fast Setup and No-Code Graphical Programming:

Featuring drag-and-drop pattern software, operators configure new box dimensions and stacking patterns in minutes without programming skills. Vacuum grippers or mechanical clamps adjust quickly to multiple carton formats.

5. OEM Custom Grippers and Conveyor Integration:

Vacuum grippers, pneumatic clamps, motorized lifting columns, and infeed roller conveyors are tailored to your carton specifications. Send your box dimensions and line speed for an engineering proposal.

Technical Parameters:

Parameter	Specification
Product Name	Collaborative Palletizing Robot
Load	20-50kg
Working radius	1780mm
Speed	5-15 carton/min
Stacking height	Under 2450mm
Repeated positioning accuracy	0.04mm
Maximum fitting tray	1200mm*1100mm
Machine size	L1700mmW1300mmH2615mm
Communication mode	TCP/IP MODBUS TCP/IO
IP level	IP54
