Features:
Technical Parameters:
- Product name:Automatic Sauce Packing Machine
- A complete set system combines of lobe pump, VIP5 model packing machine and exit conveyor.
- Make very less air in bag to maintain the product quality, especially for food.
- For normal pillow bag as well as diagonal bag.
- All parts that are contacted to the product are made of stainless steel or rust-proof material thus ensuring sanitation.
- Photo cell registration control system accurately position the photo eye-mark.
Technical Parameters:
| Model | VIP5 |
| Packing speed | 5-40 bags/min (determined by actual products) |
| Film width | 250-500mm |
| Film Material | Laminated film |
| Bag style | Pillow bag |
| Bag width | 100-235mm |
| Bag Length | 200-550mm |
| Vertical Seal Width | 8-20mm |
| Power | 2.5kw, 220v, 50Hz |
| Air Consumption | 0.4m3/min, 0.6MPa |
| Dimensions | 1380*1100*1700mm |
| Construction | Frame, electric cabinet and food contact parts are made of SUS304 |
| Options | Tear notch device Bag support Bag deflector Printer |
Scope of application
Sample bag
Production workshop
Certificate
